IP65 High Protection Single Turn Absolute Encoder Solid Shaft 11 Bit SJ38 SSI 8mm

IP65 High Protection Single Turn Absolute Encoder Solid Shaft 11 Bit SJ38 SSI 8mm

  • High Light

    Solid Shaft SSI Absolute Encoder

    ,

    Absolute Rotary Encoder 11 Bit

    ,

    Single Turn Encoder 8mm

  • Outlet Type
    Absolute Encoder Radial Cable/ Radial Socket /axial Cable With Plug /Radial Cable With Plug
  • Count Direction
    Counterclockwise/outside Control Direction /clockwise
  • Allowable Ripple
    ≤3%rms
  • Interface
    NPN Low Level Effective /NPN High Level Effetive
  • Bit(steps)
    5-11 Bit
  • Certification
    CE
  • Shaft Type
    Solid Shaft
  • External Diameter
    38mm
  • Place of Origin
    Shanghai,China
  • Brand Name
    HENGXIANG
  • Certification
    CE,ISO9001
  • Model Number
    SJ38 micro rotary encoder
  • Minimum Order Quantity
    1pcs encoder to start order
  • Price
    negotiable
  • Packaging Details
    each 1 piece was packed into single carton box
  • Delivery Time
    3-5 working days for sample order, 7-15 working days for mass order
  • Payment Terms
    D/A, D/P, T/T, Western Union, Credit Card, Master Card,Paypal, etc
  • Supply Ability
    100K pieces per year

IP65 High Protection Single Turn Absolute Encoder Solid Shaft 11 Bit SJ38 SSI 8mm

SJ38 micro rotary encoder shaft 5mm NPN output single turn absolute encoder 9 bit



1. Applications

SJ38 series encoder can be used on all kinds of applications, when you need a controller to measure speed or length, then a encoder could be worked on your device, no matter what size you need, and what precision it requested, the encoder could always be a proper tool for you.



2. Some Related S38 encoder model number

SJ38-T5NC DC5V

SJ38-Q5NHWD DC5V

SJ38-QE6NCC2 DC8V

SJ38-T6PHCC2 DC30V

SJ38-TE7NHW DC24V

SJ38-T7NHCD DC8-30V

SJ38-T8NW DC10V

SJ38-Q8NHCD DC12V

......



Specification of SJ38

Items Basic parameters
Supply voltage DC5V ; DC8-30V
Outlet type Radial cable
  Radial socket
  axial cable with plug
  Radial cable with plug
Count direction counterclockwise
  outside control direction
  clockwise
Interface NPN low level effective
  NPN high level effetive
Protection grade IP50 ; IP65
Cable length 1M (cable length could be added appropriately by
  require, but it need payment individually)
Brand HENGXIANG
Encoder type absolute encoder
External diameter 38mm
Thickness 28mm
Installation dimension 30mm diameter
Shaft length 13mm
Solid Shaft diameter 6mm D shape
Bit(steps) 5 bit;6 bit;7 bit;8bit;9bit;10 bit;11 bit;12bit
Shell Material die cast aluminum
Cable length 1000mm(cable with shielding)
Certification CE
package Carton box
Net weight About 130g (with package)
