DC30V Shaft 8mm Optical Absolute Encoder External Diameter 51mm

DC30V Shaft 8mm Optical Absolute Encoder External Diameter 51mm

  • High Light

    Shaft 8mm Optical Absolute Encoder


    Optical Absolute Encoder External Diameter 51mm


    DC30V Single Turn Absolute Encoder

  • Encoder Type
    Absolute Encoder
  • Shaft Load
    Radial 50N; Axial 30N
  • Interface
    NPN Low Level Effective/NPN High Level Effetive
  • Count Direction
    Counterclockwise /outside Control Direction /clockwise
  • Load Voltage
  • Insulation Strength
    AC500V 60s
  • Precision
    360/(resolution X 4)
  • Starting Torque
    Less Than 5x 10-3N.m
  • Top REV
    3000RPM ;IP65≤2000 RPM
  • Environmental Temperature
    Operating:-20 ~+85°C;storage:-25 ~+90°C
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
    SJ50 Encoder
  • Minimum Order Quantity
    1pcs encoder to start order
  • Price
  • Packaging Details
    each 1 piece was packed into single carton box
  • Delivery Time
    3-5 working days for sample order, 7-15 working days for mass order
  • Payment Terms
    D/A, D/P, T/T, Western Union, Credit Card, Master Card,Paypal, etc
  • Supply Ability
    100K pieces per year

DC30V Shaft 8mm Optical Absolute Encoder External Diameter 51mm

Optical absolute encoder external diameter 51mm solid shaft 8mm 4096 steps per turn


Absolute encoder model number








SJ50-T7 NH128

SJ50-C8 NH256W

SJ50-C6 NH64W

SJ50-TE6 NH64E

SJ50-TE5 NH32C


SJ50 Encoder Parameter table

Encoder type absolute encoder
External diameter 51mm
Thickness 29mm
Installation dimension 40mm diameter
Outlet type Radial cable
  Radial socket
  Radial cable with plug
Count direction counterclockwise
  outside control direction
Interface NPN low level effective
  NPN high level effetive
Insulation strength AC500V 60s
Insulation resistance 10MΩ
GND not connect to encoder
starting torque less than 5x 10-3N.m
Intertia moment less than 3x 10-6kg.m2
Shaft load Radial 50N; Axial 30N
Top REV 3000RPM ;IP65≤2000 RPM
Bearing life 1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature Operating:-20 ~+85°C;storage:-25 ~+90°C
Environmental humidity Operating and storage: 35-85%RH(noncondensing)
Certification CE
package Carton box
Net weight About 300g (with package)
